Intake manifold Malossi MHR NBR Ø22/28 mm – Minarelli horizontal

Sport intake manifold Malossi MHR is intended for scooters with Minarelli horizontal 50cc 2T engines. This is a short, straight version, developed primarily for Racing and more powerful tuning configurations with larger carburettors.

The manifold has a Ø22 mm opening and a Ø28 mm carburettor connection. It is suitable for various larger Dell’Orto, Malossi MHR Team and Mikuni carburettors with the corresponding connection.

Technical specifications

• Manufacturer: Malossi
• Series: MHR
• Type: intake manifold / intake flange
• Material: NBR rubber
• Opening: Ø22 mm
• Carburettor connection: Ø28 mm
• Inner diameter on the inlet side: Ø28 mm
• Version: short and straight
• Purpose: Sport / Racing
• For Minarelli horizontal 50cc 2T

Suitable for carburettors

With the corresponding Ø28 mm connection, the manifold is intended or suitable for:

• Dell’Orto PHVB Ø19–22 mm
• Dell’Orto PHBL Ø20–25 mm
• Malossi MHR Team carburettors
• Mikuni TM carburettors

NBR version

This is a version made of NBR rubber, which provides good resistance to fuel and oil. Malossi also offers the manifold in a Viton/FKM version, which has greater resistance to high temperatures.

Note

Before ordering, check primarily the outer diameter of the carburettor connection, which must match the Ø28 mm intake manifold connection. Due to the straight Racing design, it is also recommended to check the available space for installation of the carburettor and air filter.
